Description
GeoMax Zenith 16 is a cost-effective investment that guarantees reliable results. In combination with GeoMax field controllers and the X-PAD software, the receiver reaches its full potential.
Providing top-performing technology at an affordable price, the Zenith16 GNSS receiver convinces with a remarkable performance ratio.
The Zenith Manager, a stand-alone application available for Windows® and AndroidTM operating systems, enables you to configure your receiver without using the field controller.
GeoMax Zenith 16 Specifications
| Receiver | |
| Q-Lock ProTMÂ Functionality | Lowest noise and advanced multipath mitigation for highest reliability |
| Reliability | 99.99% |
| Measurement Engine | NovAtel OEM7, 181 channels, dual-frequency / multi-constellation |
| GPS tracking | L1, L2, L2C |
| GLONASS tracking | L1, L2, L2C |
| BeiDou tracking | B1, B2 (opt) |
| Galileo tracking | E1, E5b (opt) |
| QZSS tracking | L1, L2C (opt) |
| Positioning rate | 5 Hz |
| SBAS | EGNOS, WAAS, MSAS, GAGAN |
| Receiver Accuracy (RMS)* | |
| RTK | Hz – 10 mm + 1 ppm / V – 20 mm + 1 ppm |
| Network RTK | Hz – 10 mm + 0.5 ppm / V – 20 mm + 0.5 ppm |
| Static | Hz – 5 mm + 0.5 ppm / V – 10 mm + 0.5 ppm |
| Static – long | Hz – 3 mm + 0.1 ppm / V – 3.5 mm + 0.4 ppm |
| Interfaces                                                | |
| Keyboard | On/off and function key |
| LED status indicators | Position, battery, Bluetooth®,RTK receive, RTK transmit,data storage |
| LED mode indicators | Rover, base, static |
| Data recording | Removable microSD card |
| Communication                                      | |
| UHF radio module | SATEL, 500mW, 1000 mW transceiver, 403 – 473 MHz; (opt) |
| Bluetooth® | Device class II QR-iConnect functionality |
| TNC connector | High sensitivity, UHF antenna |
| Communication port | USB, serial & power |
| Physical                                                         | |
| Dimensions | Height 95 mm, ø 198 mm |
| Weight | 1.09 – 1.13 kg ** |
| Operating temp. | – 40°C to 65°C |
| Environmental Protection | IP68 / IP66 / MIL |
| Humidity | 100%, condensing |
| Vibration | Mechanical stress resistant according to ISO 9022-36-05 |
| Shock | Withstands 2 m drop onto hard surface |
| Power Supply | |
| Internal battery Removable, Li-Ion 2.6 Ah / 7.4 V | |
| Operating time9 h in static / 6 h in rover mode | |
| External power10.5 V to 28 V, LEMO® plug | |
| Warranty | One (1) Year Standard Warrant, Extendable Warranty (Yes) |
Check also Tersus Oscar GNSS With TC50
Product Details – GeoMax Zenith 16
- Manufacturer: GeoMax Positioning
- Model: Zenith 16
- Condition: New
- What’s in the box: GeoMax ZeniusX, Li-ion battery, Battery charger, AC/DC Adapter GK112, Case, Micro SD Card & USB, Quick guide and CD, User manual, 1-year manufacturer’s warranty
