Description
Mala Ramac X3M GPR System is an intergrated radar control unit, fitted directly on the shielded antenna and powered externally. The built-in electronic design makes it low weight and compact size system, easier to assemble and operate. No cable is required since the unit communicates directly with the laptop.
Features:
- Well designed, field-rugged enclosure
- Built-in power supply and DGPS
- Reduced footprint and weight
- Simplified graphical user interface
- In-the-field processing and interpretation
- Visible cables reduced to a minimum
- High resolution HDR controller display
- Two component system with one cable
- All antennas meet FCC, EC and IC regulatory limits on radio emissions
Mala Ramac X3M Specifications
| Pulse repetition frequency | 100 kHz (standard) |
| Data bits | 16 |
| Communication Speed | >700 kb/s |
| Data transfer rate | 40-400 kB/s at 4Mbit/s |
| Acquisition Mode | distance/time/manual |
| Operating Time | >10 hours with standard battery accessories |
| Charger | Quick Charger automatic charge cycle 110-240 VAC input |
| Charge Time | 3-5 h (80-100%) |
| Software | Compatible with Ground Vision |
| Power Supply | External 12V DC battery |
| Operating Temperature | -20ºC to +50ºC |
| Dimensions | US: 12.2 x 7 x 1.2 in. Metric: 310 x 180 x 30 mm |
Check also GSSI SIR 3000 Accurate GPR Controller
Product Details – Mala Ramac X3M
- Manufacturer: Mala
- Model: X3M
- Condition: Used, in great working condition and ready to use
- What’s in the box: Mala X3M Control Unit, Mala shielded antennas available in 250, 500 and 800MHz, Mala XV monitor, Mala Rough Terrain Cart, 3x Batteries, 3x Battery charger, 3x Power cable, Parallel communication data cable 1.8m and 3.0m, Operator’s manual
