Description
OLYMPUS OMNISCAN MX2 increases testing efficiency, ensuring superior, advanced AUT application performance with faster setups, test cycles, and reporting. In addition to universal compatibility with more than 10 phased array and ultrasound modules. Designed for NDT experts, this high-end, scalable platform delivers true next-generation NDT performance.
The OmniScan MX2 offers a high acquisition rate and new powerful software features for efficient manual and automated inspection performance—all in a portable, modular instrument.
OLYMPUS OMNISCAN MX2 Specifications
| General | Overall dimensions (W x H x D) | 325 mm x 235 mm x 130 mm (12.8 in. x 9.3 in. x 5.1 in.) |
| Weight | 3.2 kg (7 lb), no module and one battery | |
| Data Storage | Storage devices | SDHC card*, most standard USB storage devices, or fast Ethernet. *Lexar® brand memory cards are recommended for optimized results. |
| Data file size | 300 MB | |
| I/O Ports | USB ports | 3 |
| Audio alarm | Yes | |
| Video output | Video out (SVGA) | |
| Ethernet | 10/100 Mbps | |
| I/O Lines | Encoder | 2-axis encoder line (quadrature, up, down, or clock/direction) |
| Digital input | 4 digital TTL inputs, 5 V | |
| Digital output | 4 digital TTL outputs, 5 V, 15 mA | |
| Acquisition on/off switch | Remote acquisition enabled TTL, 5 V | |
| Power output line | 5 V, 500 mA power output line (short-circuit protected) | |
| Alarms | 3 TTL, 5 V, 15 mA | |
| Analog output | 2 analog outputs (12 bits) ±5 V in 10 kΩ | |
| Pace input | 5 V TTL pace input | |
| Display | Display size | 26.4 cm (10.4 in.) (diagonal) |
| Resolution | 800 pixels x 600 pixels | |
| Brightness | 700 cd/m2 | |
| Number of colors | 16 million | |
| Type | TFT LCD | |
| Power Supply | Battery type | Smart Li-ion battery |
| Number of batteries | 1 or 2 (battery chamber accommodates two hot-swappable batteries) | |
| Battery life | Minimum 7 hours with two batteries | |
| Environmental Specifications | Operating temperature range | -10 °C to 45 °C (14 ºF to 113 ºF) |
| Storage temperature range | -20 °C to 60 °C (-4 ºF to 140 ºF) with batteries -20 °C to 70 °C (-4 ºF to 158 ºF) without batteries |
|
| Relative humidity | Max. 70% RH at 45°C noncondensing | |
| Ingress Protection Rating | Designed for IP66 | |
| Shockproof rating | Drop-tested according to MIL-STD-810G 516.6 |
Check also Olympus Nortec 600D Eddy Current Flaw Detector
Product Details – OLYMPUS OMNISCAN MX2
- Manufacturer: Olympus
- Model: OMNISCAN MX2
- Condition: Used, in great working condition and ready to use
- What’s in the box: 2 Batteries, AC Adapter/Charger, Power Cord, User Manual On Cd-ROM, Carrying Case
